Ball Joint Application Guide

Title:
Ball Joint Application Guide

The Ball Joint Application Guide is a manual that is used in conjunction with OTC ball joint adapters and "C" frame. The manual provides a Year-Make-Model lookup to determine which ball joint adapters are to be used with the "C" frame to remove and install ball joints. The manual includes a lookup chart that provides removal and installation adapter part numbers and an application diagram section with visual examples of how the tools are oriented for removal and installation.

The Tabs

Overview
SKU:
6529MAN-17
Categories:
Specialty Tools
Suspension
Includes:
Printed manual, 150 pages
Related/Accessory Products:
Ball Joint Master Service Kit
Ball Joint Service Kit (Cars)
Ball Joint Service Kit (Trucks)
Specs
Product Specs:
Pages | 150
Features:
Year-Make-Model lookup chart listing removal and installation adapter requirements
Application diagram section to show assembly of adapters and C Frame to remove and install ball joints
Ball joint identification chart shows adapter photo and part numbers
Product Dimensions:
11 × 8.5 × 0.375 in
Product Weight:
1.1 lb
Shipping Weight:
1.1 lb
